BRADEN introduces TR25 and TR35 Hydraulic Planetary Winches

Built around BRADEN’s proven planetary gear technology, the TR Series delivers the fast line speeds, high efficiency, and continuous-duty performance required for real-world recovery work. A compact, low-profile housing allows each model to fit into tight installation envelopes, while the industry-standard 18 in. mounting bolt pattern ensures the TR25 and TR35 serve as direct replacements for existing hydraulic winches, offering more power without redesigning equipment.

Both models feature a rugged, highly efficient gear train and a drum supported by low-friction ball bearings to reduce power loss under load. Durable urethane brake seals provide long-lasting protection in abrasive environments, and the oil bath lubrication system simplifies service and extends component life. Operators can choose between manual or air-actuated freespool clutch engagement depending on application needs.

The TR25 delivers a 25 000 lb (11 340 kg) rated line pull and is available in short or long drum configurations to match different rope capacity requirements. It accommodates 9/16 in. (14 mm) or 5/8 in. (16 mm) wire or synthetic rope. The larger TR35 offers a 35 000 lb (15 876 kg) rated line pull with capacity for 155 ft (47.2 m) of ¾ in. (19 mm) wire rope. Both models are fully compliant with SAE J706 winch performance standards.

The TR Series was developed with both equipment manufacturers and operators in mind. Delivering dependable pulling power in a highly versatile design, with simple installation and maintenance requirements, the TR25 and TR35 deliver value to OEMs, upfitters, and end users needing reliable, high-capacity winching solutions.

Image: TR35.
